PRODUCT TYPE DIMENSIONS DIAMETER DISC DIAMETER  CODE
FLANGE DİSC 1/2" 150# 90mm TP1000 1/2" 150#
FLANGE DİSC 3/4" 150# 100mm TP1000 3/4" 150#
FLANGE DİSC 1" 150# 109mm TP1000 1" 150#
FLANGE DİSC 1 1/2 150# 128mm TP1000 1 1/2 150#
FLANGE DİSC 2" 150# 153mm TPI000 2" 150#
FLANGE DİSC 2 1/2" 150# 179mm TP1000 2 1/2" 150#
FLANGE DİSC 3" 150# 191mm TP1000 3" 150#
FLANGE DİSC 3 1/2 150# 217mm 1 TP1000 3 1/2" 150#
FLANGE DİSC 4" 150# 230mm TP1000 4" 150#
FLANGE DİSC 5" 150# 255mm TP1000 5" 150#
FLANGE DİSC 6" 150# 280mm TP1000 6" 150#
FLANGE DİSC 8" 150# 344mm TP1000 8" 150#
FLANGE DİSC 10" 150# 407mm TP1000 10" 150#
FLANGE DİSC 12" 150# 484mm TP1000 12" 150#
FLANGE DİSC 14" 150# 534mm TP1000 14" 150#
FLANGE DİSC 16" 150# 598mm TP1000 16" 150#
FLANGE DİSC 18" 150# 636mm TP1000 18" 150#
FLANGE DİSC 20" 150# 699mm TP1000 20" 150#
FLANGE DİSC 24" 150# 814mm TP1000 24" 150#
FLANGE DİSC 26" 150# 871mm TP1000 26" 150#
FLANGE DİSC 28" 150# 928mm TP1000 28" 150#
FLANGE DİSC 30" 150# 985mm TP1000 30" 150#
FLANGE DİSC 32" 150# 1062mm TP1000 32" 150#
FLANGE DİSC 34" 150# 1112mm TP1000 34" 150#
FLANGE DİSC 36" 150# 1170mm TP1000 36" 150#
FLANGE DİSC 38" 150# 1239mm TP1000 38" 150#
FLANGE DİSC 40" 150# 1290mm TP1000 40" 150#
FLANGE DİSC 42" 150# 1347mm TP1000 42" 150#
FLANGE DİSC 44" 150# 1404mm TP1000 44" 150#
FLANGE DİSC 46" 150# 1455mm TP1000 46" 150#
FLANGE DİSC 1/2" 300# 96mm TP1000 1/2" 300#
FLANGE DİSC 3/4" 300# 118mm TP1000 3/4" 300#
FLANGE DİSC 1" 300# 125mm TP1000 1" 300#
FLANGE DİSC 1 1/4" 300# 134mm TP1000 1 1/4" 300#
FLANGE DİSC 1 1/2" 300# 157mm TP1000 1 1/2" 300#
FLANGE DİSC 2" 300# 166mm TP1000 2" 300#
FLANGE DİSC 2 1/2" 300# 191mm TP1000 2 1/2" 300#
FLANGE DİSC 3" 300# 211mm TP1000 3" 300#
FLANGE DİSC 3 1/2" 300# 215,9mm TP1000 3 1/2" 300#
FLANGE DİSC 4" 300# 255mm TP1000 4" 300#
FLANGE DİSC 5" 300# 280mm TP1000 5" 300#
FLANGE DİSC 6" 300# 319mm TP1000 6" 300#
FLANGE DİSC 8" 300# 382mm TP1000 8" 300#
FLANGE DİSC 10" 300# 445mm TP1000 10" 300#
FLANGE DİSC 12" 300# 522mm TP1000 12" 300#
FLANGE DİSC 14" 300# 585mm TP1000 14" 300#
FLANGE DİSC 16" 300# 649mm TP1000 16" 300#
FLANGE DİSC 18" 300# 712mm TP1000 18" 300#
FLANGE DİSC 20" 300# 776mm TP1000 20" 300#
FLANGE DİSC 24" 300# 915mm TP1000 24" 300#
FLANGE DİSC 26" 300# 973mm  TP1000 26" 300#
FLANGE DİSC 28" 300# 1036mm TP1000 28" 300#
FLANGE DİSC 30" 300# 1093mm  TP1000 30" 300#
FLANGE DİSC 32" 300# 1151mm  TP1000 32" 300#
FLANGE DİSC 34" 300# 1208mm TP1000 34" 300#
FLANGE DİSC 36" 300# 1271mm  TP1000 36" 300#
FLANGE DİSC 42" 300# 1290mm  TP1000 42" 300#
FLANGE DİSC 1/2" 600# 96mm  TP1000 1/2 600#
FLANGE DİSC 3/4" 600# 118mm TP1000 3/4" 600#
FLANGE DİSC  1" 600# 125mm  TP1000 1" 600#
FLANGE DİSC 1 1/2 600# 157mm  TP1000 1 1/2" 600#
FLANGE DİSC 2" 600# 165mm  TP1000 2" 600#
FLANGE DİSC 3" 600# 211mm  TP1000 3" 600#
FLANGE DİSC 4" 600# 274mm  TP1000 4" 600#
FLANGE DİSC 5" 600# 330,2mm  TP1000 5" 600#
FLANGE DİSC 6" 600# 357mm  TP1000 6" 600#
FLANGE DİSC 8" 600# 420mm  TP1000 8" 600#
FLANGE DİSC 10" 600# 509mm  TP1000 10" 600#
FLANGE DİSC 12" 600# 560mm  TP1000 12" 600#
FLANGE DİSC 14" 600# 604mm  TP1000 14" 600#
FLANGE DİSC 16" 600# 687mm TP1000 16" 600#
FLANGE DİSC 18" 600# 744mm TP1000 18" 600#
FLANGE DİSC 20" 600# 814mm  TP1000 20" 600#
FLANGE DİSC 24" 600# 941mm  TP1000 24" 600#
FLANGE DİSC 26" 600# 1017m TP1000 26" 600#
FLANGE DİSC 28" 600# 1074mm  TP1000 28" 600#
FLANGE DİSC 30" 600# 1134mm  TP1000 30" 600#
FLANGE DİSC 32" 600# 1195mm  TP1000 32" 600#
FLANGE DİSC 34" 600# 1246rnm  TP1000 34" 600#
FLANGE DİSC 36" 600# 1316mm  TP1000 36" 600#
FLANGE DİSC 3" 900# 242mm  TP1000 3" 900#
FLANGE DİSC 4" 900# 293mm  TP1000 4" 900#
FLANGE DİSC 6" 900# 382mrn  TP1000 6" 900#
FLANGE DİSC 8" 900# 471mm  TP1000 8" 900#
FLANGE DİSC 10" 900# 547mm  TP1000 10" 900#
FLANGE DİSC 12" 900# 611mm  TP1000 12" 900#
FLANGE DİSC 14" 900# 642mm  TP1000 14" 900#
FLANGE DİSC 16" 900# 7. mm  TP1000 16" 900#
FLANGE DİSC 18" 900# 788mm  TP1000 18" 900#
FLANGE DİSC 20" 900# 858mm  TP1000 20" 900#
FLANGE DİSC 24" 900# .2mm   TP1000 24" 900#
FLANGE DİSC 30" 900# 1233mm  TP1000 30" 900#
FLANGE DİSC 1/2" 1500# 122mm TP1000 1/2" 1500#
FLANGE DİSC 3/4" 1500# 131mm   TP1000 3/4" 1500#
FLANGE DİSC 1" 1500# 150mm  TP1000 1" 1500#
FLANGE DİSC 1 1/2" 1500# 179mm TP1000 1 1/2" 1500#
FLANGE DİSC 2" 1500# 217mm  TP1000 2" 1500#
FLANGE DİSC 3" 1500# 268mm  TP1000 3" 1500#
FLANGE DİSC 4" 1500# 312mm TP1000 4" 1500#
FLANGE DİSC 6" 1500# 395mm TP1000 6" 1500#
FLANGE DİSC 8" 1500# 484mm TP1000 8" 1500#
FLANGE DİSC 10" 1500# 585mm TP1000 10" 1500#
FLANGE DİSC 12" 1500# 674mm TP1000 12" 1500#
FLANGE DİSC 14" 1500# 750mm TP1000 14" 1500#
FLANGE DİSC 16" 1500# 827mm  TP1000 16" 1500#
FLANGE DİSC 18" 1500# 915mm TP1000 18" 1500#
FLANGE DİSC 20" 1500# 985mm TP1000 20" 1500#
FLANGE DİSC 24" 1500# 1169mm TP1000 20" 1500#
